Features

Design pressure (PS1 / DP2):

Ambient temperature (TS1):

Inlet gas temperature:

Inlet pressure (MAOP / pumax1):

Range of downstream pressure (Wd1):

Available accessories:

Minimum operating differential pressure (Δpmin1):

Accuracy class (AC1):

Lock-up pressure class (SG1):

Nominal size (DN1,2):

Connections:

Values

up to 1 MPa for BP, up to 2 MPa for MP and TR

up to 10 bar for BP, up to 20 bar for MP and TR

from -20 °C to +60 °C from -4 °F to +140 °F

from -20 °C to +60 °C from -4 °F to +140 °F

• from (Pd + 0.01) MPa to 1 MPa from BPfrom (Pd + 0.01) MPa to 2 MPa for MP and TR

• from (Pd + 0.1) bar to 10 bar from BPfrom (Pd + 0.1) bar to 20 bar for MP and TR

• from 1.3 to 10 kPa for BP, from 10 to 30 kPa for MP, from 30 to 250 kPa for TR

• from 13 to 100 mbar for BP, from 100 to 300 mbar for MP, from 300 to 2500 mbar for TR

LA slam shut, relief valve, monitor version

0.01 MPa | 0.1 barg

up to 10

up to 20 (depending on version and set point)

DN 1”x1”; DN 1”x1” 1/2

Threaded Rp EN 10226-1, NPT ASME B1.20.1
