Features

Values

Operating Range

0-100% water cut
0-92% gas volume fraction (GVF)

Typical Uncertainty (95% CL)

Liquid flow rate* ±3% (0-80% GVF) ±4% (80-92% GVF)
Gas flow rate* ±7% (0-92% GVF)
Water cut ±3% (0-60% GVF) ±4% (60-80% GVF) ±5% (80-92% GVF)

Size

Starting from 0.5’’

Design Pressure & Temperature

Up to 10.000 psi (690 bar), up to 302 °F (150 °C)

Meter pressure drop

<1 bar

Communication interface

Communication ports
•     RS-485 single or redundant
•     RS-422 single or redundant
•     Ethernet single or redundant Communication protocols
•     Modbus ASCII/RTU
•     TCP/IP

Flow Electronic Transmitter

•     Real Time controller, Linux operating system
•     Ambient temperature -40 °C / +75 °C
•     Power supply: 24VDC or 110÷240 VAC, 50÷60Hz
•     Power consumption: 15W@24VDC
•     Enclosure for safe or hazardous area
•     Weather protection: IP66
•     Stainless steel or aluminum enclosure
•     Field display (optional)
•     ATEX/IECEx certification Ex d (or Ex ia) IIB T3-T6 Ga

HMI

HMI for Windows
