Features

Design pressure (DP):

Inlet pressure range:

Regulator capacity:

Adjustment rangeof downstream pressure:

Accuracy class (AC):

Lock-up over pressure (SG):

Operating ambient temperature:

Permissible gas temperature:

Inlet connection:

Outlet connection:

Modular connections:

Values

0.86 MPa 8.6 bar

0.01 - 0.86 MPa 0.1 - 8.6 bar

1765 - 3530 ft3/h 50 - 100 m3/h

BP Version 1.3 - 9.9 kPa 13 - 99 mbar

MP version 10 - 35 kPa 100 - 350 mbar

10

20

Standard ver. from -20 °C to +60 °C from -4 °F to +140 °F

Low temperature ver. (Subzero) from -40°C to +60°C from -40 °F to +140 °F

Standard ver. from -10°C to +60°C from +14 °F to +140 °F

Low temperature ver. (Subzero) from -20 °C to +60 °C from -4 °F to +140 °F

G 1” EN ISO 228/1(modular connections on request)

• In-line outlet: G 1” 1/2 EN ISO 228/1

• Outlet in a square pattern: G 1” 1/2” ENISO 228/1

(modular connections on request)

• Gas (as per UNI EN ISO 228-1:2003);

• Flat swivel joint (as per NF E29-533: 2014 and NF E29-536: 2017);

• NPT (according to ASME B1.20.1, excluding connections with metal/metal sealing);

• Special accessories (on request).
