Features

Design pressure:

Ambient temperature:

Inlet gas temperature range:

Available Accessories:

Accuracy class AG:

Over pressure setting range (OPSO):

Under pressure setting range (UPSO):

Nominal dimensions DN:

Connections:

End to end dimensions:

Values

up to 10.2 MPa up to 102 barg

from -20 °C to +60 °C from -4 °F to +140 °F

from -20 °C to +60 °C from -4 °F to +140 °F

Limit switch, remote tripping

up to 2.5 for OPSO (depending on working conditions)

up to 2.5 for UPSO (depending on working conditions)

from 2 KPa to 9 MPa from 20 mbarg to 90 barg

from 1 KPa to 9 MPa from 10 mbarg to 90 barg

DN 25 / 1”; DN 50 / 2”; DN 80 / 3”; DN 100 / 4”;

DN 150 / 6”; DN 200 / 8”; DN 250 / 10”

Class 150/300/600 RF / RTJ according to ASME B 16.5 or

PN 16/25/40 according to EN 1092-1

according to EN 334, EN 14382
